Selecting the correct 2016 chevy silverado oil type is the single most critical task for protecting your EcoTec3 engine against premature internal mechanical wear. At Vroomdan, our team of experienced mechanics cut through dealership confusion to bring you exact fluid capacities, filter specifications, and torque values. Beyond keeping your truck running smoothly, taking control of basic maintenance reveals how many engineered shortcuts Chevy built into your pickup—including brilliant cabin storage features that most drivers overlook completely.
Your Silverado has a secret compartment hiding above your glove box.
And 8 other things Chevy never told you.
Hidden dash storage · Key fob window trick · Auto 4WD mode · Buckle to Drive · and 5 more.
▶ Read Now — Show Me Everything
bryansgarage.com · Bryan Mark · 2026
In This Guide
- Viscosity & Fluid Specs: Factory-recommended 0W-20 and 5W-30 dexos1 synthetic oil grades.
- Capacity Breakdown: Exact 6.0-quart and 8.0-quart engine oil change capacities.
- Filter Part Numbers: OEM ACDelco filter specifications and pressure valve ratings.
- Step-by-Step Maintenance: Complete DIY oil change tutorial, torque limits, and dashboard display reset.
Step-by-Step Guide to 2016 Chevy Silverado Oil Type, Capacity, and Filter Specs
Performing a routine oil service on your pickup ensures maximum longevity for key mechanical components like valve lifters and camshafts.
Changing your own engine fluid saves money and guarantees that high-quality synthetic lubricants enter your motor.
Before beginning your service, gather all necessary tools and safety gear to streamline the maintenance process.
Required Tools and Equipment
- 15mm socket and ratchet wrench
- ACDelco oil filter wrench or end-cap socket
- Drain pan with at least 10-quart holding capacity
- Funnel and lint-free shop towels
- Safety glasses and nitrile gloves
- ACDelco PF63E professional oil filter
- Required volume of dexos1 certified synthetic motor oil
Estimated Time Needed: 30 to 45 minutes.
Step 1: Vehicle Preparation and Elevation
Park your truck on a solid, level concrete surface and engage the parking brake firmly.
Run the engine for three minutes to warm the motor fluid slightly so suspended contaminants drain out freely.
Turn off the ignition, remove the keys, and raise the front end using a hydraulic jack rated for light-duty trucks.
Secure the frame rails on heavy-duty jack stands before crawling underneath the chassis.
Step 2: Draining the Used Engine Oil
Locate the steel oil pan and the 15mm drain plug facing toward the rear of the vehicle.
Position your catch container directly beneath the drain plug to capture the high-velocity fluid stream.
Using your 15mm socket, loosen the plug counterclockwise and remove it carefully by hand.
Allow the fluid to drain completely for at least ten minutes until it slows to a sparse drop.
Inspect the rubber O-ring seal on the drain bolt for cracking or tears before reinstalling it.
Tighten the drain plug by hand first, then torque it to 18 lb-ft using a calibrated torque wrench.
Step 3: Removing and Replacing the Oil Filter
Position the drain pan directly underneath the oil filter housing located on the lower driver side of the engine block.
Loosen the old filter using your filter wrench and spin it off slowly by hand.
Verify that the old rubber gasket came off with the filter housing and is not stuck to the engine mating surface.
Wipe the engine mounting pad clean using a fresh shop rag to remove old debris and residual oil.
Apply a thin film of clean engine fluid around the rubber sealing ring of your new ACDelco PF63E filter.
Thread the new filter on by hand until the rubber gasket contacts the engine mounting face.
Turn the filter an additional three-quarters to one full turn by hand to establish a secure seal without crushing the internal threads.
Step 4: Refilling with Clean Synthetic Oil
Remove the oil filler cap located on the passenger side valve cover under the hood.
Insert a clean funnel into the neck to avoid spilling synthetic oil onto the exhaust manifold.
Pour in the exact recommended fluid volume based on your specific engine displacement.
Reinstall the oil filler cap securely and wipe away any minor surface drips.
Step 5: Verification and Final Checks
Start the engine and allow it to idle smoothly for two minutes while monitoring the instrument cluster oil pressure gauge.
Check under the truck for any sign of leakage around the drain plug or oil filter mounting pad.
Shut off the engine, wait five minutes for the fluid to settle into the sump, and pull the dipstick.
Wipe the dipstick clean, reinsert it completely, and check that the fluid level sits squarely within the crosshatched zone.
At Vroomdan, we emphasize following these exact factory steps to keep your truck running in peak condition without paying steep service shop rates.
Engine Variations: 2016 Chevy Silverado 1500 Oil Capacity and Viscosity Breakdown
General Motors engineered three distinct EcoTec3 engine variants for the 2016 model year.
Each motor utilizes direct injection, variable valve timing, and Active Fuel Management (AFM) cylinder deactivation technology.
Because these systems rely on precise oil pressure to actuate internal lifters, choosing the exact viscosity index is vital.
Understanding your specific 2016 chevy silverado 1500 oil type prevents catastrophic valve-train tick and lifter collapse.
| Engine Option | Viscosity Grade | 2016 Chevy Silverado Oil Capacity | OEM Filter Spec |
|---|---|---|---|
| 4.3L EcoTec3 V6 (LV3) | SAE 5W-30 (dexos1) | 6.0 Quarts (5.7 Liters) | ACDelco PF63E |
| 5.3L EcoTec3 V8 (L83) | SAE 0W-20 (dexos1) | 8.0 Quarts (7.6 Liters) | ACDelco PF63E |
| 6.2L EcoTec3 V8 (L86) | SAE 0W-20 (dexos1) | 8.0 Quarts (7.6 Liters) | ACDelco PF63E |
The standard 5.3L V8 engine requires full synthetic oil to ensure instant hydraulic pressure reaches the AFM solenoids during cold starts.
Exceeding or underfilling the total 2016 chevy silverado 1500 oil capacity leads to excessive fluid foaming or severe friction damage.
General Motors specifically mandates the dexos1 Gen 2 or Gen 3 specification standard across all EcoTec3 gasoline powerplants.
This synthetic specification includes anti-foaming agents and low-volatility additives designed to combat low-speed pre-ignition (LSPI).
ACDelco Oil Filter Specifications and Bypass Valve Mechanics
Using the correct oil filter is just as important as filling your engine crankcase with the proper fluid grade.
The primary OEM oil filter designated for the 2016 Silverado 1500 lineup is the ACDelco PF63E.
Older Chevy models utilized the shorter PF48 filter, but GM issued a technical service bulletin updating the specification to the longer PF63E canister.
The updated PF63E filter contains an internal bypass valve calibrated specifically to 22 PSI (150 kPa).
This higher bypass pressure prevents unfiltered oil from circulating through your engine during cold starts when fluid viscosity is heavy.
Installing an aftermarket filter with a lower 12 PSI bypass rating allows dirty fluid to bypass the filtration media regularly.
The filter features a synthetic-blend filtration media capable of trapping micro-particles down to 30 microns in size.
It also incorporates an internal silicone anti-drainback valve that prevents fluid from draining out of the upper cylinder head overnight.
Practical Application Guide and Preventive Maintenance Schedule
Maintaining a strict service schedule protects your investment and maintains your truck’s towing capability over hundreds of thousands of miles.
Under normal highway driving conditions, change your motor oil and filter every 7,500 miles or 12 months, whichever comes first.
If you regularly tow heavy trailers, idle excessively, or drive in extreme cold or dusty off-road environments, shorten your interval to 5,000 miles.
Always inspect your engine bay monthly for minor seepage around the valve cover gaskets and oil cooler lines.
Keep a spare quart of dexos1 synthetic oil stored safely in your truck cab for top-offs during long road trips.
Overcoming Common DIY Maintenance Mistakes
Even experienced home mechanics occasionally make minor oversights that cause major headache down the road.
The most frequent DIY error is failing to notice a double-gasket condition on the filter housing pad.
If the old rubber gasket sticks to the engine block and you screw the new filter over it, oil will blow out under high pressure upon engine start.
Another common mistake is overtightening the steel drain plug on the aluminum pan, which strips out delicate threads.
Always use a hand socket or calibrated torque wrench rather than an impact gun when securing oil pan hardware.
Never substitute non-dexos approved conventional motor oil into an EcoTec3 engine, as conventional oil breaks down rapidly under intense cylinder heat.
Frequently Asked Questions
Can I use SAE 5W-20 instead of 0W-20 in my 2016 Silverado 5.3L V8?
General Motors strictly specifies 0W-20 full synthetic motor oil for the 5.3L and 6.2L EcoTec3 V8 engines under all operating temperatures.
Using 5W-20 fluid increases internal hydraulic drag during cold starts and can cause delayed engagement of the Active Fuel Management lifters.
What happens if I overfill the 2016 Chevy Silverado oil capacity?
Overfilling the crankcase causes the spinning crankshaft counterweights to whip air into the standing oil pool, creating dense fluid foam.
Aerated foam cannot be pressurized effectively by the oil pump, leading to sudden oil pressure drops and potential bearing damage.
How do I reset the oil life display percentage on my dashboard?
Turn the ignition key to the ON position without starting the engine.
Use the steering wheel directional keypad to scroll through the Driver Information Center menu until you reach the Oil Life display screen.
Press and hold the checkmark button for several seconds until a confirmation tone sounds and the display resets to 100%.
Will changing my own engine oil at home void my vehicle warranty?
No, performing your own oil maintenance does not void your vehicle warranty under the federal Magnuson-Moss Warranty Act.
Always keep purchase receipts for your synthetic oil and ACDelco filters along with a written log of service dates and mileages.
“I’ve driven a Silverado for 5 years and didn’t know this existed.”
— The most common reaction when this article is shared
Did you know there’s a hidden storage compartment behind your rear seats? Or the button combo that switches your digital cluster to a completely different layout?
bryansgarage.com · July 28, 2026
Conclusion
Maintaining proper fluid levels and using factory-certified lubricants protects your Silverado’s EcoTec3 engine against mechanical wear and costly repair bills.
Ready to get the most out of your truck? Check out more guides on Vroomdan or email us at contact@vroomdan.com — our team is here to help you discover more truck secrets and maintenance guides.
Disclaimer: Always consult your official Chevy Owner’s Manual before performing any DIY modifications. Information provided is for educational purposes and depends on specific vehicle model years, trim levels, and individual modifications.
